Section F-4: WATER PUMP/VERTICAL SHAFT (L SIZE) (v2)
Diagram for section F-4: WATER PUMP/VERTICAL SHAFT (L SIZE).
| Ref | Part No. | Qty | Buy |
|---|---|---|---|
| 1 |
12216ZE2300
CLIP, VALVE GUIDE
|
1 | Ask on WhatsApp |
| 2 |
15332ZW9000
GUIDE, OIL (S,L)
|
1 | Ask on WhatsApp |
| 3 |
19210ZW9003
IMPELLER, PUMP (S,L)
|
1 | Ask on WhatsApp |
| 4 |
19215ZW9000
HOUSING ASSY., IMPELLER
|
1 | Ask on WhatsApp |
| 5 |
19231ZW9000
COVER, IMPELLER
|
1 | Ask on WhatsApp |
| 6 |
19232ZW9000
GASKET, IMPELLER
|
1 | Ask on WhatsApp |
| 7 |
19240ZW9000
HOUSING COMP., WATER PUMP (S,L)
|
1 | Ask on WhatsApp |
| 8 |
19243ZW9000
GROMMET, WATER PUMP HOUSING
|
1 | Ask on WhatsApp |
| 9 |
19251ZW9000
TUBE, WATER (S)
|
1 | Ask on WhatsApp |
| 9 |
19251ZW9630
TUBE, WATER (L)
|
1 | Ask on WhatsApp |
| 10 |
19253ZW9000
RING, WATER TUBE SEAL
|
1 | Ask on WhatsApp |
| 11 |
24311ZW9300
ROD B, SHIFT (S)
|
1 | Ask on WhatsApp |
| 11 |
24311ZW9630
ROD B, SHIFT (L)
|
1 | Ask on WhatsApp |
| 12 |
24312ZV7000
JOINT, SHIFT ROD
|
1 | Ask on WhatsApp |
| 13 |
24320ZW9000
ROD A, SHIFT (S)
|
1 | Ask on WhatsApp |
| 13 |
24320ZW9630
ROD A, SHIFT (L)
|
1 | Ask on WhatsApp |
| 14 |
24341ZW9300
ROD, PUSH
|
1 | Ask on WhatsApp |
| 15 |
41112ZW9000
SHAFT, VERTICAL (S)
|
1 | Ask on WhatsApp |
| 15 |
41112ZW9630
SHAFT, VERTICAL (L)
|
1 | Ask on WhatsApp |
| 16 |
41116ZW9000
SLINGER, OIL (S,L)
|
1 | Ask on WhatsApp |
| 17 |
41131ZW9000
GEAR, PINION
|
1 | Ask on WhatsApp |
| 18 |
41135ZW9000
WASHER A, THRUST BEARING
|
1 | Ask on WhatsApp |
| 19 |
41136ZW9000
WASHER B, THRUST BEARING
|
1 | Ask on WhatsApp |
| 19 |
41137ZW9000
WASHER C, THRUST BEARING
|
1 | Ask on WhatsApp |
