Suzuki DF150 – OPT:HARNESS (1)
OPT:HARNESS (1) (v2)
Model code: DF150
Parts list
OPT:HARNESS (1)
| Ref | Part No. / Description | Qty | Buy |
|---|---|---|---|
| 1 |
17917-87L00
CONNECTOR, FLUSH WATER
|
1 |
Price: 14.90 AED
Stock: 49
|
| 1-1 |
36620-93J10
df150t-e01
WIRE ASSY, REMOCON EXTENSION
L:2000
|
1 | |
| 1-1 |
36620-93J10
df150t-e40
WIRE ASSY, REMOCON EXTENSION
L:2000
|
1 | |
| 1-1 |
36620-93J10
df150z-e01
WIRE ASSY, REMOCON EXTENSION
L:2000
|
1 | |
| 1-1 |
36620-93J10
df150z-e40
WIRE ASSY, REMOCON EXTENSION
L:2000
|
1 | |
| 1-2 |
36620-93J40
df150t-e01
WIRE ASSY, REMOCON EXTENSION
L:3000
|
1 | |
| 1-2 |
36620-93J40
df150t-e40
WIRE ASSY, REMOCON EXTENSION
L:3000
|
1 | |
| 1-2 |
36620-93J40
df150z-e01
WIRE ASSY, REMOCON EXTENSION
L:3000
|
1 | |
| 1-2 |
36620-93J40
df150z-e40
WIRE ASSY, REMOCON EXTENSION
L:3000
|
1 | |
| 2 |
34660-96J00
KIT, WATER PRESS GAUGE
|
1 | |
| 2 |
36620-93J30
df150t-e01
WIRE ASSY, REMOCON ADAPTER
|
1 | |
| 2 |
36620-93J30
df150t-e40
WIRE ASSY, REMOCON ADAPTER
|
1 | |
| 2 |
36620-93J30
df150z-e01
WIRE ASSY, REMOCON ADAPTER
|
1 | |
| 2 |
36620-93J30
df150z-e40
WIRE ASSY, REMOCON ADAPTER
|
1 | |
| 3 |
09352-50903-600
.HOSE (5X9X600)
L:600->70
|
1 | |
| 4 |
09367-06006
.3 WAY
|
1 | |
| 4 |
38500-93J00
df150t-e01
BUZZER ASSY, WARNING
|
1 | |
| 4 |
38500-93J00
df150t-e40
BUZZER ASSY, WARNING
|
1 | |
| 4 |
38500-93J00
df150z-e01
BUZZER ASSY, WARNING
|
1 | |
| 4 |
38500-93J00
df150z-e40
BUZZER ASSY, WARNING
|
1 | |
| 5 |
09401-08413
.CLIP
|
3 |
Price: 3.72 AED
Stock: 124
|
| 6 |
33830-96J00
SET, BATTERY ISOLATOR LEAD
|
1 | |
| 7 |
09407-10404
.CLAMP (L:100)
|
2 | |
| 8 |
09481-30401
.FUSE (30A)
|
1 |
Price: 11.92 AED
Stock: 5
|
| 9 |
36990-87D00
TERMINAL SET, WITH SLEEVE
|
1 |
