F70LA

Section 32: OPTIONAL PARTS 1 (v2)

Engine sections in this catalog
TOP COWLING FUEL INJECTION PUMP 2 OIL PUMP FUEL 1 FUEL 2 GENERATOR ELECTRICAL 1 ELECTRICAL 2 ELECTRICAL 3 ELECTRICAL 4 STARTING MOTOR CYLINDER & CRANKCASE 1 BOTTOM COWLING 1 BOTTOM COWLING 2 CONTROL BRACKET 1 BRACKET 2 POWER TRIM & TILT ASSY 1 POWER TRIM & TILT ASSY 2 UPPER CASING OIL PAN LOWER CASING & DRIVE 1 CRANKSHAFT & PISTON LOWER CASING & DRIVE 2 STEERING GUIDE OPTIONAL PARTS 1 OPTIONAL PARTS 2 OPTIONAL PARTS 3 OPTIONAL PARTS 4 OPTIONAL PARTS 5 REPAIR KIT 1 REPAIR KIT 2 CYLINDER & CRANKCASE 2 VALVE INTAKE 1 INTAKE 2 INTAKE 3 FUEL INJECTION PUMP 1
F70LA – section 32 OPTIONAL PARTS 1 parts diagram

Diagram for section 32: OPTIONAL PARTS 1.

Ref Part No. Qty Buy
2
6A5-48129-10
.SCREW 3
 2 Ask on WhatsApp
2
6X4-42111-02-8D
HANDLE, STEERING
 1 Ask on WhatsApp
2
90201-12035
WASHER, PLATE
 2 Ask on WhatsApp
3
6X4-42821-00
.BAND, CLAMP
 3 Ask on WhatsApp
3
90386-12003
BUSH
 2 Ask on WhatsApp
3
93700-06M03
NIPPLE, GREASE
 1 Ask on WhatsApp
4
6X4-48215-00
GRAPHIC
 1 Ask on WhatsApp
4
92990-12600
WASHER, PLATE
 1 Ask on WhatsApp
4
97095-08040
BOLT
 1
Price: 10.43 AED
In stock (1 pcs)
5
6X4-42119-01
GRIP, STEERING HANDLE
 1 Ask on WhatsApp
5
90185-12M12
NUT, SELF-LOCKING
 1 Ask on WhatsApp
5
92995-08600
WASHER
 1 Ask on WhatsApp
6
6X4-42177-00
RUBBER, HANDLE
 1 Ask on WhatsApp
6
6X4-42728-10
CAP
 1 Ask on WhatsApp
6
97095-06030
BOLT
 2 Ask on WhatsApp
7
6X4-42137-00
INDICATOR, THROTTLE
 1 Ask on WhatsApp
7
92995-06600
WASHER
 2 Ask on WhatsApp
8
6X4-41291-00
BUSHING
 1 Ask on WhatsApp
8
6X4-48538-00
CLAMP, CABLE 1
 1 Ask on WhatsApp
9
6X4-26367-00
PROTECTOR
 1 Ask on WhatsApp
9
6X4-44139-01
COLLAR
 1 Ask on WhatsApp
10
90152-05007
SCREW, COUNTERSUNK
 1 Ask on WhatsApp
10
97095-06014
BOLT
 1 Ask on WhatsApp
11
6X4-48538-10
CLAMP, CABLE 1
 1 Ask on WhatsApp
11
91490-20010
PIN. COTTER
 1 Ask on WhatsApp
12
6X4-26367-00
PROTECTOR
 1 Ask on WhatsApp
12
6X4-44177-00
WASHER
 2 Ask on WhatsApp
13
6X4-42128-00
COLLAR, DISTANCE 1
 1 Ask on WhatsApp
13
97095-06014
BOLT
 1 Ask on WhatsApp
14
6X4-42159-00
STAY
 1 Ask on WhatsApp
14
90501-23215
SPRING, COMPRESSION
 1 Ask on WhatsApp
15
6X4-44159-00-8D
HANDLE, GEAR SHIFT
 1 Ask on WhatsApp
15
6X4-44188-00
WASHER
 2 Ask on WhatsApp
16
6X4-44173-00
LEVER, SHIFT CONTROL
 1 Ask on WhatsApp
16
90386-08032
BUSH
 1
Price: 8.94 AED
In stock (25 pcs)
17
63D-42126-00
FRICTION, STEERING HANDLE GRIP
 1 Ask on WhatsApp
17
97780-60920
SCREW, TAPPING
 2 Ask on WhatsApp
18
6G8-44191-00
INDICATOR, SHIFT
 1 Ask on WhatsApp
18
6X4-48154-00
KNOB, THROTTLE
 1 Ask on WhatsApp
19
90386-26MA3
BUSH
 2 Ask on WhatsApp
19
95380-06600
NUT, HEXAGON
 1
Price: 3.72 AED
In stock (5 pcs)
20
6X4-42131-01
COVER, HANDLE STEERING
 1 Ask on WhatsApp
20
91490-20010
PIN. COTTER
 1 Ask on WhatsApp
21
6X4-44100-00
SHIFT LINK ASSY
 1 Ask on WhatsApp
21
97885-06016
SCREW, PAN HEAD
 6
Price: 2.98 AED
In stock (12 pcs)
22
6X4-42115-00
.SHAFT, STEERING HANDLE
 1 Ask on WhatsApp
22
92995-06600
WASHER
 6 Ask on WhatsApp
23
6X4-42725-01
GROMMET
 1 Ask on WhatsApp
23
6X4-44102-00
.SHIFT ASSIST ASSY.
 1 Ask on WhatsApp
24
63D-42121-22-8D
BRACKET
 1 Ask on WhatsApp
24
6X4-47731-00
.GEAR, DRIVE
 1 Ask on WhatsApp
25
6X4-44132-00
.BUSHING
 1 Ask on WhatsApp
25
90101-12014
BOLT
 1 Ask on WhatsApp
26
6X4-14137-00
.CLIP
 1 Ask on WhatsApp
26
92990-12200
WASHER, PLAIN
 1
Price: 2.98 AED
In stock (19 pcs)
27
6X4-48261-00
.ARM, THROTTLE
 1 Ask on WhatsApp
27
90206-12M22
WASHER, WAVE
 1 Ask on WhatsApp
28
6X4-82540-00
.NEUTRAL SWITCH ASSY
 1 Ask on WhatsApp
28
90387-12M02
COLLAR
 1 Ask on WhatsApp
