AG100
Section 9: STARTER (v2)
Model code: AG100
Parts list
Section 9
| Ref | Part No. / Description | Qty | Buy |
|---|---|---|---|
| 1 |
3V6-15660-02
KICK AXLE ASSY
|
1 | |
| 2 |
305-15641-00
GEAR, KICK (261)
|
1 | |
| 3 |
90468-26048
CLIP
|
1 | |
| 4 |
248-15654-00
HOLDER. KICK GEAR
|
2 | |
| 5 |
99009-30400
CIRCLIP
|
1 | |
| 6 |
90508-26441
SPRING. TORSION
|
1 | |
| 7 |
3V6-15664-00
GUIDE, SPRING
|
1 | |
| 8 |
3V6-15676-00
COVER, SPRING
|
1 | |
| 9 |
3V6-15666-01
SPACER
|
1 | |
| 10 |
248-15668-00
STOPPER
|
1 |
5.21 AED
Check price & stock on WhatsApp
|
| 11 |
93104-20017
OIL SEAL
|
1 | |
| 12 |
403-15651-00
GEAR, KICK IDLE (26T)
|
1 | |
| 13 |
90201-13200
WASHER. PLATE
|
1 | |
| 14 |
99009-13400
CIRCLIP
|
1 | |
| 15 |
3V6-15620-00
KICK CRANK ASSY
|
1 | |
| 16 |
90504-18009
.SPRING, COMPRESSION
|
1 | |
| 17 |
214-15616-00
WASHER, KICK LEVER
|
1 | |
| 18 |
93440-11029
.CIRCLIP
|
1 | |
| 19 |
214-15618-00
.COVER, KICK LEVER
|
1 | |
| 20 |
97027-08030
BOLT
|
1 | |
| 21 |
90201-206E5
WASHER. PLATE (0.9T)
|
1 |
