YFM25RD
Section 22: FRONT SUSPENSION & WHEEL (v2)
Model code: 1BTM
Parts list
Section 22
| Ref | Part No. / Description | Qty | Buy |
|---|---|---|---|
| 1 |
4D3-23570-00-33
FRONT LOWER ARM COMP. (LEFT)
YB
|
1 | |
| 2 |
90381-15088
BUSH, SOLID
|
4 | |
| 3 |
5YT-23517-00
COVER, THRUST 1
|
4 | |
| 4 |
90387-101R3
COLLAR
|
2 | |
| 5 |
90105-10241
BOLT, FLANGE
|
2 | |
| 6 |
90185-10012
NUT, SELF-LOCKING
|
2 | |
| 7 |
93700-06004
NIPPLE, GREASE
|
2 | |
| 8 |
4D3-23580-00-33
FRONT LOWER ARM COMP. (RIGHT)
YB
|
1 | |
| 9 |
90381-15088
BUSH, SOLID
|
4 | |
| 10 |
5YT-23517-00
COVER, THRUST 1
|
4 | |
| 11 |
90387-101R3
COLLAR
|
2 | |
| 12 |
90105-10241
BOLT, FLANGE
|
2 | |
| 13 |
90185-10012
NUT, SELF-LOCKING
|
2 | |
| 14 |
93700-06004
NIPPLE, GREASE
|
2 | |
| 15 |
4D3-23540-00-33
FRONT UPPER ARM COMP. (LEFT)
YB
|
1 | |
| 16 |
90381-15088
BUSH, SOLID
|
2 | |
| 17 |
5YT-23517-00
COVER, THRUST 1
|
2 | |
| 18 |
90387-100Y6
COLLAR
|
1 |
49.91 AED
Check price & stock on WhatsApp
|
| 19 |
109-22141-01
SHAFT, PIVOT
|
1 | |
| 20 |
90201-10035
WASHER, PLATE
|
1 | |
| 21 |
90185-10012
NUT, SELF-LOCKING
|
1 | |
| 22 |
93700-06004
NIPPLE, GREASE
|
1 | |
| 23 |
4D3-23550-00-33
FRONT UPPER ARM COMP. (RIGHT)
YB
|
1 | |
| 24 |
90381-15088
BUSH, SOLID
|
2 | |
| 25 |
5YT-23517-00
COVER, THRUST 1
|
2 | |
| 26 |
90387-100Y6
COLLAR
|
1 |
49.91 AED
Check price & stock on WhatsApp
|
| 27 |
109-22141-01
SHAFT, PIVOT
|
1 | |
| 28 |
90201-10035
WASHER, PLATE
|
1 | |
| 29 |
90185-10012
NUT, SELF-LOCKING
|
1 | |
| 30 |
93700-06004
NIPPLE, GREASE
|
1 | |
| 31 |
4D3-23350-20
SHOCK ABSORBER ASSY
UR FOR DPBSE
|
2 | |
| 31 |
4D3-23350-00
SHOCK ABSORBER ASSY
UR FOR BWS1
|
2 | |
| 32 |
90105-10131
BOLT, FLANGE
|
4 | |
| 33 |
90185-10012
NUT, SELF-LOCKING
|
4 | |
| 34 |
90201-10035
WASHER, PLATE
|
2 | |
| 35 |
90171-10001
NUT, CASTLE
|
2 | |
| 36 |
91401-20020
PIN, COTTER
|
2 | |
| 37 |
90171-10001
NUT, CASTLE
|
2 | |
| 38 |
91401-20020
PIN, COTTER
|
2 | |
| 39 |
3GD-23501-10
STEERING KNUCKLE ASSY (LEFT)
|
1 | |
| 40 |
3GD-23502-10
STEERING KNUCKLE ASSY (RIGHT)
|
1 |
