ME432STIP2
Section 10: INTAKE MANIFOLD (v2)
Model code: N701
Parts list
Section 10
| Ref | Part No. / Description | Qty | Buy |
|---|---|---|---|
| 1 |
YU1-71111-70-40
MANIFOLD,INTAKE
|
1 | |
| 2 |
YU1-71711-70-30
GASKET,INTAKE MANIFOLD
|
2 | |
| 3 |
YU9-01260-80-36
STUD,HEX LOBULAR
|
2 | |
| 4 |
YU9-01790-80-40
NUT
|
8 | |
| 5 |
YU9-09020-20-03
WASHER,PLETE
|
8 | |
| 6 |
YU9-21126-08-25
BOLT,STUD
|
8 | |
| 7 |
YU1-71731-70-30
GASKET, EXHAUST MANIFOLD
SEE FIG.31-4
|
2 | |
| 8 |
YU1-98101-70-30
HEARTER ASSY, INTAKE
SEE FIG.28-36
|
1 | |
| 9 |
YU1-98291-70-10
GASKET, INTAKE HEARTER
SEE FIG.28-39
|
2 |
