Yamaha 40XMH, 40XW Section 14 Parts Diagram
CONTROL
28 catalog rows · 7 linked store rows
Yamaha 40XMH, 40XW CONTROL parts
Yamaha 40XMH, 40XW section 14 covers control parts for this outboard catalog. The list includes PULLEY, SPRING 1, COLLAR, LEVER, MAGNETO CONTROL, JOINT, LINK, SPRING, COMPRESSION, SCREW, PAN HEAD, NUT. Use the diagram reference numbers with the parts table to identify the correct item.
7 rows in this section are linked to store products with live price or availability. Confirm the exact model, serial range and year before ordering marine engine parts.
Parts list
Section 14
| Ref | Part No. / Description | Qty | Buy |
|---|---|---|---|
|
Ref
1
|
PULLEY
1
|
Qty 1 | |
|
Ref
2
|
SPRING 1
1
|
Qty 1 | |
|
Ref
3
|
COLLAR
1
|
Qty 1 | |
|
Ref
4
|
LEVER, MAGNETO CONTROL
1
|
Qty 1 | |
|
Ref
5
|
JOINT, LINK
1
|
Qty 1 | |
|
Ref
6
|
SPRING, COMPRESSION
1
|
Qty 1 | |
|
Ref
7
|
SCREW, PAN HEAD
1
|
Qty 1 | |
|
Ref
8
|
NUT
1
|
Qty 1 | |
|
Ref
9
|
CAP
1
|
Qty 1 | |
|
Ref
10
|
STAY, THROTTLE WIRE
1
|
Qty 1 | |
|
Ref
11
|
WASHER, PLATE
1
|
Qty 1 | |
|
Ref
12
|
BOLT
1
|
Qty 1 | |
|
Ref
13
|
BOLT
1
|
Qty 1 | |
|
Ref
14
|
LEVER, SHIFT ROD
1
|
Qty 1 | |
|
Ref
15
|
BUSHING, SHIFT ROD LEVER
1
|
Qty 1 | |
|
Ref
16
|
PIN, SPRING
1
|
Qty 1 | |
|
Ref
17
|
BRACKET
2
|
Qty 2 | |
|
Ref
18
|
BOLT
4
|
Qty 4 | |
|
Ref
19
|
SPRING
1
|
Qty 1 | |
|
Ref
20
|
BOLT
1
|
Qty 1 | |
|
Ref
21
|
ROD, SHIFT
S
|
Qty 1 | |
|
Ref
21
|
ROD, SHIFT
1 L
|
Qty 1 | |
|
Ref
22
|
PIN, COTTER
1
|
Qty 1 | |
|
Ref
23
|
LEVER, SHIFT ROD
1
|
Qty 1 | |
|
Ref
24
|
PIN, SPRING
1
|
Qty 1 | |
|
Ref
25
|
CABLE END, REMOTE CONTROL
|
Qty 2 | |
|
Ref
26
|
CLIP
|
Qty 2 | |
|
Ref
27
|
CLAMP, CABLE
1
|
Qty 1 |
